🔹 Tube Sheets (Heat Exchanger Tube Plates)
Tube Sheets are key components used in heat exchangers, boilers, condensers and pressure vessels. They are designed to support and fix tube bundles and serve as pressure-retaining parts in thermal equipment.
Tube Sheets are usually manufactured according to customer drawings and project specifications, requiring precise machining and strict quality control.
🔹 Product Scope
We supply custom-made Tube Sheets including:
- Drilled Tube Sheets
- Plain Tube Sheets
- Tube Sheets for Heat Exchangers
- Tube Sheets for Condensers
- Tube Sheets for Boilers
- Special design Tube Sheets based on drawings
🔹 Standards
Our Tube Sheets are manufactured in accordance with:
- ASME Section VIII
- TEMA Standards
- ASTM material standards
- EN 13445
- DIN / JIS (upon request)
Custom standards and project specifications are supported.
🔹 Materials
Available materials include:
- Carbon Steel
- Stainless Steel
- Alloy Steel
- Duplex Stainless Steel
Typical grades:
- ASTM A516 Gr.70
- ASTM A240 304 / 316
- ASTM A182 F304 / F316
- ASTM A350 LF2
Other materials available upon request.
🔹 Manufacturing & Machining
Our Tube Sheets are produced through:
- Plate cutting
- CNC drilling and machining
- Precision hole positioning
- Surface finishing
- Heat treatment (if required)
We ensure:
- Accurate hole diameter and pitch
- Smooth surface finish
- Strict dimensional tolerance
🔹 Inspection & Testing
Quality inspection includes:
- Dimensional inspection
- Material certification (MTC EN10204 3.1)
- Visual inspection
- Ultrasonic testing (UT)
- PMI testing (optional)
🔹 Applications
Tube Sheets are widely used in:
- Heat exchangers
- Boilers and condensers
- Oil & gas industry
- Chemical and petrochemical plants
- Power plants
- Marine and offshore equipment
🔹 Why Choose Our Tube Sheets
- Custom fabrication according to drawings
- Advanced CNC machining capability
- Strict quality control system
- Export experience for global projects
- Reliable delivery time
